What Causes High Resistance In A Circuit Resistance opposition to current flow in a circuit Connection anomalies pose resistance problems in our motor circuits and if they are not identified and corrected they can have deleterious effects Normal things that affect circuit resistance are conductor resistance length of the wire size of the wire in circular mils

Flowing in a circuit is affected by the resistance of that circuit Each component in a circuit has a resistance Can you answer these questions based on the video What happens to the current The resistance in a circuit depends on several factors such as the material the circuit is made of the length and thickness of the material and the temperature of the material Generally materials with high resistivity longer length and smaller cross sectional area will have higher resistance
