10mm Nut To Standard Metric Nut Thickness The nut thickness shall be the overall distance measured parallel to the axis of nut from the top of the nut to the bearing surface and shall include the thickness of the washer face where provided Standard Metric Hex Nuts Types Styles 1 and 2 per ANSI ASME B18 2 4 1M and B18 2 4 2M All dimensions are in millimeters
The charts below show metric bolt conversions to standard bolt conversions and DIN numbers for fasteners To assist in ordering we offer metric bolt conversion data for industrial bolts rods machine screws and small diameter fasteners including Below is a general guide for spanner sizes corresponding to standard metric and imperial nut sizes Metric ISO Nuts M6 Nut Spanner Size 10 mm M8 Nut Spanner Size 13 mm M10 Nut Spanner Size 17 mm M12 Nut Spanner Size 19 mm M14 Nut Spanner Size 22 mm M16 Nut Spanner Size 24 mm M20 Nut Spanner Size 30 mm M24 Nut
