M1 6 Screw Dimensions M1 6 Basic Thread Dimensions Pitch minor major diameters depth lead Tolerance range for all applicable classes and much more
ISO 4762 specifies the characteristics of hexagon socket head cap screws with coarse pitch thread from M1 6 up to and including M64 and product grade A All dimensions are in millimeters Drilled head metric hexagon socket head cap screws normally are not available in screw sizes smaller than M3 nor larger than M36 The M3 and M4 nominal screw sizes have two drilled holes spaced 180 degrees apart
